WESTERN PACIFIC · 2011 SEASON
Typhoon Nanmadol (2011)
Recorded track and intensity · 21 Aug 2011–31 Aug 2011
Drag to pan · Pinch or Ctrl/⌘ + scroll to zoom. Keyboard: plus or minus to zoom, arrow keys to pan, and 0 to show the full track.
Wind speed & pressure
26 Aug, 06:00 UTCForward speed & ACE
26 Aug, 06:00 UTCHover or tap either graph to follow the track. The slider controls both graphs. Each line uses its matching colored axis.
Forward speed measures the center’s motion. ACE accumulates squared one-minute winds at 00, 06, 12 and 18 UTC during tropical or subtropical stages at 34 kt or above. Missing observations make ACE partial. Missing measurements remain gaps.
161 mph / 259 km/h
26 Aug 2011 · tropical stage
Full archive record, including non-tropical stages if present
Along the recorded center positions
STORM HISTORY
Track and intensity summary
Nanmadol is listed in the Western Pacific basin for the 2011 season. Its archived track begins on 21 Aug 2011, 06:00 UTC at 11.9°N, 128.8°E. US-agency wind is not available for this first observation. These dates describe the available observations, which may include stages before and after the tropical cyclone phase.
The first Category 5 observation appears on 26 Aug 2011, 03:00 UTC. The highest recorded tropical-stage one-minute sustained wind is 140 knots (161 mph / 259 km/h), first recorded on 26 Aug 2011, 06:00 UTC at 17.2°N, 123.6°E. The minimum recorded tropical-stage central pressure is 918 hPa on 26 Aug 2011, 06:00 UTC.
The full record spans 246 hours and approximately 2,170 kilometers along the recorded center positions. The last recorded position is 24.4°N, 116.9°E on 31 Aug 2011, 12:00 UTC.
This summary is calculated from the NOAA IBTrACS archive. Category 5 describes the storm’s peak recorded wind intensity, not its intensity at landfall or the severity of impacts at any location. Landfall times, damage and casualties have not been independently reviewed for this page.
METHODOLOGY
Data sources and limitations
The map and summary are generated from NOAA’s IBTrACS v04r01 archive. Wind and category use US-agency records; minimum pressure is calculated during the tropical stage, with the archive’s pressure source retained. Category 5 refers to the Saffir–Simpson one-minute wind scale; local agencies may use different classifications. Coastlines use Natural Earth’s 1:10m land data.
Track distance adds great-circle distances between consecutive observations, excluding gaps over 12 hours. This track has no gaps over 12 hours. The line shows the storm’s center, not its size, rainfall or flood extent. Converted wind speeds are rounded to the nearest whole unit.
Archive retrieved
NOAA IBTrACS archive · Field documentation
